Use this 16A circuit breaker (MCB) to protect a circuit that needs a little more power than a small lighting circuit. The Schrack BMS4 disconnects both conductors as soon as the current rises too high or a short circuit occurs. This keeps the cables in your walls within their safe limits.
What is a 16 A MCB for?
On a 1.5 mm² conductor, 16 A is the highest rating that AREI (the Belgian electrical installation regulations) permits in homes. That is why you will often find it on:
- lighting circuits with many lighting points
- a dedicated circuit for a fixed appliance, such as a cooker hood or air conditioning unit
- the circuit for a small solar inverter, if the manual specifies 16 A
Because both poles are protected, it can be used in a 3×230 V network, where every circuit is connected between two phases, as well as in a 3N×400 V network.
Key features
- twin terminals top and bottom: connect a busbar and a cable together
- supply from the top or the bottom, as you prefer
- contact gap of at least 4 mm, so it also serves as an isolator
- low let-through energy (class 3), which improves selectivity with upstream fuses
Installation and connection
This MCB takes up two modules on the DIN rail. Because the terminals are open on both sides, a busbar can run along the top as well as the bottom, which keeps a full row of MCBs neat and tidy. The terminals accept conductors from 1 to 25 mm².
Good to know
This MCB is designed for alternating current. For direct current, Schrack specifies a maximum of 48 V per pole, so the DC side of a solar panel system requires separate DC protection. Installation is a job for a qualified electrician, and once the work is complete, a mandatory inspection by an approved inspection body follows.
| Product code | BM417216 (Schrack BMS4 C 16/2) |
|---|---|
| EAN | 9004840390452 |
| Rated current | 16 A |
| Tripping curve | C |
| Poles | 2P, both poles protected |
| Breaking capacity | 4.5 kA (EN 60898-1), 6 kA (EN 60947-2) |
| Rated voltage | 230/400 V AC, 50/60 Hz |
| Width | 2 modules (approx. 35 mm) |
| Terminal capacity | 1 to 25 mm² |
| Power loss | 4.7 W |
| Max. back-up fuse | 80 A gG |
| Degree of protection | IP20, IP40 with cover |
| Ambient temperature | -5 °C to +40 °C (calibrated at 30 °C) |
| Standards | EN 60898-1, EN 60947-2 |
| Reference | 9004840390452 |
| Category | Circuit breakers and RCDs |
| Merk | Schrack |
| Weight | 0.24 kg |
