In Belgian homes, a 20A circuit breaker (MCB) goes with 2.5 mm² cable. This Schrack BMS4 protects both conductors of the circuit and trips as soon as the current stays too high for too long or a short circuit occurs.
Use in the home
AREI (the Belgian electrical installation regulations) allows an MCB of up to 20 A on 2.5 mm² cable in homes. That is why you often see this rating on:
- socket circuits in the living area, kitchen or bedrooms
- a dedicated circuit for a washing machine, tumble dryer or dishwasher
- an oven or an electric water heater
For washing machine, tumble dryer and dishwasher circuits, AREI also requires a 30 mA residual current device (RCD).
Benefits
- two protected poles, suitable for both 3×230 V and 3N×400 V networks
- C tripping curve: only trips magnetically at 5 to 10 times the rated current, so a motor starting up will not cause nuisance tripping
- can be mounted in any position
- flexible conductors can be connected using bootlace ferrules
Installation and connection
The MCB clips onto a standard DIN rail, alongside your other modular devices. Properly tightened terminals (2 to 2.4 Nm, according to Schrack) prevent connections from overheating. With the consumer unit cover fitted, it achieves IP40.
Good to know
Have the MCB installed by a qualified electrician, who will also decide which circuits are grouped on which RCD. After a new connection or an extension, the installation must be inspected by an approved inspection body.
| Product code | BM417220 (Schrack BMS4 C 20/2) |
|---|---|
| EAN | 9004840390469 |
| Rated current | 20 A |
| Tripping curve | C |
| Poles | 2P, both poles protected |
| Breaking capacity | 4.5 kA (EN 60898-1), 6 kA (EN 60947-2) |
| Rated voltage | 230/400 V AC, 50/60 Hz |
| Width | 2 modules (approx. 35 mm) |
| Terminal capacity | 1 to 25 mm² |
| Power loss | 6.6 W |
| Max. back-up fuse | 80 A gG |
| Degree of protection | IP20, IP40 with cover |
| Ambient temperature | -5 °C to +40 °C (calibrated at 30 °C) |
| Standards | EN 60898-1, EN 60947-2 |
| Reference | 9004840390469 |
| Category | Circuit breakers and RCDs |
| Merk | Schrack |
| Weight | 0.24 kg |
