This 25A circuit breaker (MCB) is intended for circuits that demand more than a socket circuit can handle. It protects both poles against overload and short circuit. Thanks to its C characteristic, it stays on during the brief current surge when a compressor or motor starts.
When do you choose 25 A?
In a home, AREI (the Belgian electrical installation regulations) requires a conductor of at least 4 mm² for a 25 A MCB. Typical applications:
- an electric cooker or a smaller hob on 230 V
- a heat pump or air conditioning unit for which the manufacturer specifies 25 A
- the supply cable to a sub-board in the garage, the garden shed or the loft
In a 3×230 V network, a circuit like this is connected between two phases. With its two protected poles, this MCB is suitable for such circuits, just as it is for a 3N×400 V network.
Benefits
- calibrated at 30 °C, with correction curves from Schrack for warmer or cooler enclosures
- breaks short-circuit currents up to 4.5 kA to EN 60898-1, the standard for household installations
- toggle can be locked during maintenance
- can be extended with an auxiliary contact, fault signal contact or shunt trip
Connection in the consumer unit
With a cable of 4 mm² or more, you have plenty of margin: the terminals accept up to 25 mm², solid or flexible with a bootlace ferrule. The supply can come in from the top or the bottom, and the twin terminals also let you connect a busbar.
Good to know
Always follow the electrical rating stated in the appliance's manual. Choosing the cable and the MCB, as well as the installation itself, is a job for a qualified electrician, and the installation must then be inspected by an approved inspection body.
| Product code | BM417225 (Schrack BMS4 C 25/2) |
|---|---|
| EAN | 9004840390476 |
| Rated current | 25 A |
| Tripping curve | C |
| Poles | 2P, both poles protected |
| Breaking capacity | 4.5 kA (EN 60898-1), 6 kA (EN 60947-2) |
| Rated voltage | 230/400 V AC, 50/60 Hz |
| Width | 2 modules (approx. 35 mm) |
| Terminal capacity | 1 to 25 mm² |
| Power loss | 6.4 W |
| Max. back-up fuse | 80 A gG |
| Degree of protection | IP20, IP40 with cover |
| Ambient temperature | -5 °C to +40 °C (calibrated at 30 °C) |
| Standards | EN 60898-1, EN 60947-2 |
| Reference | 9004840390476 |
| Category | Circuit breakers and RCDs |
| Merk | Schrack |
| Weight | 0.24 kg |
