A 50A circuit breaker (MCB) protects a supply cable rather than an ordinary circuit: the cable from the main consumer unit to a sub-board, or a heavy single-phase load. Both poles are protected.
When do you choose 50 A?
- supplying a sub-distribution board in an outbuilding, garage or workshop
- a heavy single-phase load for which the manufacturer specifies 50 A
A 50 A rating calls for a heavy cable; the electrician calculates the cross-section in accordance with AREI (the Belgian electrical installation regulations) and checks whether your supply and the upstream protection can handle that load.
Benefits
- energy limiting class 3: low let-through energy in the event of a short circuit
- twin terminals on both sides, for conductors up to 25 mm²
- top or bottom feed, any mounting orientation
- IP20, IP40 with cover
Installation and connection
This heavy-duty MCB, the Schrack BMS4 C 50/2 (BM417250), takes up only 2 modules, approximately 35 mm. It is designed for a rated voltage of 230/400 V AC at 50/60 Hz. The terminals accept conductors from 1 to 25 mm². The breaking capacity is 4.5 kA to EN 60898-1 and 6 kA to EN 60947-2. The MCB is calibrated at 30 °C and suitable for ambient temperatures from -5 °C to +40 °C.
Good to know
Leave the installation to a qualified electrician. If you modify or extend your installation, you must then have it inspected by an approved inspection body, as AREI requires.
| Product code | BM417250 (Schrack BMS4 C 50/2) |
|---|---|
| EAN | 9004840508987 |
| Rated current | 50 A |
| Tripping curve | C |
| Poles | 2P, both poles protected |
| Breaking capacity | 4.5 kA (EN 60898-1), 6 kA (EN 60947-2) |
| Rated voltage | 230/400 V AC, 50/60 Hz |
| Width | 2 modules (approx. 35 mm) |
| Terminal capacity | 1 to 25 mm² |
| Degree of protection | IP20, IP40 with cover |
| Ambient temperature | -5 °C to +40 °C (calibrated at 30 °C) |
| Standards | EN 60898-1, EN 60947-2 |
| Reference | 9004840508987 |
| Category | Circuit breakers and RCDs |
| Merk | Schrack |
| Weight | 0.24 kg |
