This 4-pole 10A circuit breaker (MCB) has three protected poles for the phases and a fourth pole for the neutral. The neutral switches on and off with the phases but has no protection of its own, which is why Schrack calls this 3P+N. This means that in the event of a fault or during maintenance, all conductors of the circuit are disconnected at the same time.
Which circuits is a 10 A 3P+N MCB intended for?
This version is intended for a network with a neutral conductor: the 3N×400 V network. In a 3×230 V network without neutral, a 3-pole MCB is used instead. With 10 A per phase, you can protect loads such as:
- the inverter of a smaller three-phase solar installation, if the manufacturer specifies 10 A
- a low-power three-phase pump or compressor
- a small three-phase machine in the workshop
Benefits
- all four poles switch together, so the circuit is completely isolated
- C tripping curve: brief motor starting currents do not cause nuisance tripping
- red or green contact position indicator on each pole
- tested to EN 60898-1 (4.5 kA) and EN 60947-2 (6 kA)
Installation and connection
At 4 modules wide, this MCB takes up as much space as four single-pole units. The neutral pole is on the right and is marked N on the device, at terminals 7 and 8. Always connect the neutral conductor there, never a phase.
Good to know
Because the neutral is not protected, your electrician will check that the neutral conductor cannot become overloaded. Call in a qualified electrician for the installation; an inspector from an approved inspection body must then check the modified installation.
| Product code | BM417810 (Schrack BMS4 C 10/3N) |
|---|---|
| EAN | 9004840390858 |
| Rated current | 10 A |
| Tripping curve | C |
| Poles | 3P+N: 3 protected poles, switched neutral (not protected) |
| Breaking capacity | 4.5 kA (EN 60898-1), 6 kA (EN 60947-2) |
| Rated voltage | 230/400 V AC, 50/60 Hz |
| Width | 4 modules (approx. 70 mm) |
| Terminal capacity | 1 to 25 mm² |
| Power loss | 4.7 W |
| Max. back-up fuse | 80 A gG |
| Degree of protection | IP20, IP40 with cover |
| Ambient temperature | -5 °C to +40 °C (calibrated at 30 °C) |
| Standards | EN 60898-1, EN 60947-2 |
| Reference | 9004840390858 |
| Category | Circuit breakers and RCDs |
| Merk | Schrack |
| Weight | 0.46 kg |
