Use this 4-pole 16A circuit breaker (MCB) to protect a three-phase appliance that draws up to 16 A per phase. Each of the three phase poles has thermal and magnetic protection, while the neutral is switched without protection. If a fault occurs on one phase, all poles switch off together.
What is 16 A per phase used for?
- an 11 kW EV charger (16 A per phase)
- a three-phase heat pump or inverter, if the manual calls for 16 A
- a compressor, table saw or other three-phase machine in your workshop
It is used in an installation with a neutral conductor. If your home has a 3×230 V network without neutral, the electrician will fit a 3-pole MCB instead.
Benefits
- meets the requirements for insulation coordination and can serve as an isolator
- lift and cage terminals top and bottom, also suitable for a busbar
- red/green contact position indicator on each pole
- compact: 4 modules wide
Installation and connection
The BMS4 clips onto a standard DIN rail and can be mounted in any orientation. It makes no difference whether you connect the supply at the top or the bottom. The terminals accept conductors from 1 to 25 mm²; for an EV charger, the electrician chooses the cross-section based on cable length and power.
Good to know
For an EV charger, the manufacturer usually also specifies a particular type of residual current device (RCD), unless the charger itself detects DC fault currents. Have this assessed by a qualified electrician, who will also connect the charger. Before the new circuit is put into use, the installation must be inspected by an approved inspection body.
| Product code | BM417816 (Schrack BMS4 C 16/3N) |
|---|---|
| EAN | 9004840390865 |
| Rated current | 16 A |
| Tripping curve | C |
| Poles | 3P+N: 3 protected poles, switched neutral (not protected) |
| Breaking capacity | 4.5 kA (EN 60898-1), 6 kA (EN 60947-2) |
| Rated voltage | 230/400 V AC, 50/60 Hz |
| Width | 4 modules (approx. 70 mm) |
| Terminal capacity | 1 to 25 mm² |
| Power loss | 7.2 W |
| Max. back-up fuse | 80 A gG |
| Degree of protection | IP20, IP40 with cover |
| Ambient temperature | -5 °C to +40 °C (calibrated at 30 °C) |
| Standards | EN 60898-1, EN 60947-2 |
| Reference | 9004840390865 |
| Category | Circuit breakers and RCDs |
| Merk | Schrack |
| Weight | 0.46 kg |
